Elevate™ 150 x 50mm Pocket CentreGLAZE™ shopfront framing system is designed to accept thick glass with 20.50mm wide by 22.50mm deep glazing product.
- Matching heavy duty 50mm thick doors that will also accept thick using snap on glazing beads.
- High water resistance can be achieved using the appropriate mullion combinations. Water resistance 600Pa, based on Series 624 results.
- Braced fixed framing bead designed to stay in place under high negative wind loads.
- We have included additional central screw ports to keep the joints tight and waterproof and support the weight of extra heavy glass units.
- Two fully beaded midrail sizes to choose from (125 and 120mm deep) that will give the 20.50mm wide glazing pocket.
- Sub-head, sub-sills and two-piece sub-jamb to assist with installation.
